Maintenance Object Repair Procedures
555-233-123
10-868 Issue 4 May 2002
6 FAIL The suffix of the firmware image file on the source board does
not match the suffix entered on the screen. The firmware image
file is incorrect for the board types entered on the screen.
Execute list directory and verify that a file system is enabled on
the board and the file is present.
If the correct firmware image is not present, FTP the correct
firmware image to the source board.
Execute change firmware download and enter the new file
name on the screen.
7 FAIL The source board entered on the screen is not present.
Execute display firmware download and verify the source
board location.
Verify the source boards translations.
If the location is incorrect, execute change firmware download
and enter the correct location on the screen
8 FAIL The source boards entered on the screen are incorrect. The
board could have been changed after the schedule was entered.
Execute list config. verify the source board location.
Execute change firmware download and enter the correct
location on the screen.
PASS Firmware download to this circuit pack is successful.
0NO
BOARD
The test could not relate the internal ID to the port (no board).
This could be due to incorrect translations, no board is inserted,
an incorrect board is inserted, or an insane board is inserted.
Ensure that the board translations are correct.
If the board was already administered correctly, check the error
log to determine whether the board is hyperactive. If this is the
case, the board is shut down. Reseating the board re-initializes
the board.
If the board was found to be correctly inserted in step 1, then
issue the busyout board UUCSS command.
Issue the reset board UUCSS command.
Issue the release board UUCSS command.
Issue the test board UUCSS long command.
This should re-establish the linkage between the internal ID and
the port.
Table 10-312. TEST #1413 Firmware Download Test — Continued
Error
Code
Test
Result Description/ Recommendation
Continued on next page
