ISDN-PLK (ISDN-PRI Signaling Link Port)
Issue 4 May 2002
10-945555-233-123
e. “Transmit FIFO Overflow error” This error indicates that the circuit pack is
having problems transmitting data to the Packet Bus, thus affecting the
conveyance of signaling information over the D-channel. Specifically, this
error occurs when the Packet Bus transmit buffers overflow. This condition
probably indicates a hardware problem.
The actual alarming level depends on the options chosen via the set
options command on the G3-MT terminal. ISDN-PRI Signaling Link Port
alarms are treated as Station alarms, and their default alarming option is to
downgrade all alarms to Warning. The value shown in the preceding table
indicates the normal, unfiltered case (option “y” on the Set Options form).
f. “Bad DLCI error” This error occurs when a LAPD frame is received across
the DS1 facility which contains a DLCI which does not have a valid entry in
the on-board translation memory. This error normally indicates an off-board
problem usually related to a broken endpoint or a state mismatch between
a remote endpoint and the local call processing software. Maintenance will
not start any testing or generate any alarms in response to this error.
g. “Receive FIFO Overflow error” This error occurs when the circuit pack
detects an overflow of its receive buffers. If it occurs frequently, it may
indicate a LAPD parameter mismatch between the two end-points of a
packet switched connection. LAPD should be able to recover from this
problem, but it may degrade the performance of the Packet Bus.
Maintenance will not start any testing or generate any alarms in response
to this error.
h. This error occurs when the Signaling Port Packet Bus Loopback Test
(#939) fails. Run the long test sequence and pay particular attention to the
results of Test #939.
System Technician-Demanded Tests: Descriptions
and Error Codes
Always investigate tests in the order presented in the table below when inspecting
errors in the system. REMINDER: The command line entry to test the ISDN-PLK
MO is: test port PCSSpp (sh or l), where ‘pp’ is ‘24’ for 24-channel interfaces,
and ‘16’ for 32-channel interfaces.
Order of Investigation
Short Test
Sequence
Long Test
Sequence D/ND
1
1 D = Destructive; ND = Nondestructive
Signaling Port Bus Loopback Test (#939) X D
Signaling Link Board Check (#643) X X ND
