Maintenance Object Repair Procedures
555-233-123
10-1040 Issue 4 May 2002
NOTE:
Local restore of a complete system from the PCMCIA disk should not
require more than 20 minutes assuming that a replacement MAPD pack is
available and pre-loaded with the IP trunk application software.
Restoring data from the PCMCIA disk
Before you start
1. Shut down the application running on the circuit pack. See ‘‘Shutting down
NT on the TN802’’.
2. Remove the defective IP Trunk circuit pack from the switch (if applicable).
3. Install the replacement IP Trunk circuit pack in the switch (if applicable).
4. Insert the backup diskette into the IP Trunk circuit pack.
Table 10-377. Backing up TN802 administration data
Step Description Comments
1. Busyout circuit pack At the Avaya DEFINITY Server terminal type
busyout board UUCSS (the address of the
TN802 circuit pack) and press
Enter.
2. Backup administration
TN802 to disk
At the Windows NT desktop, double-click on the IP
Trunk Backup Restore icon.
The IP Trunk Backup/Restore Utility screen
appears.
3. Select utility In the IP Trunk Backup/Restore Utility dialog
screen, click on Files, Backup.
The IP Trunk Backup screen appears.
4. Select backup In the IP Trunk Backup screen, click on the
Backup button
5. Wait Backup can take as much as 20 minutes to
complete.
6. Release circuit pack At the Avaya DEFINITY Server terminal type
release board UUCss (the address of the TN802
circuit pack) and press
Enter.
Continued on next page
