Maintenance Object Repair Procedures
555-233-123
10-1082 Issue 4 May 2002
Notes:
a. Error Type 1 - For the TN802B only, this error type indicates that less than
three DSPs are out of service (OOS), and no alarm is raised. The Aux Data
field contains the number of DSPs that are Out of Service (OOS).
b. Error Type 18 - the MEDPRO has been busied out by busyout port
UUCSS.
1. Release the port (release port UUCSS).
c. Error Type 258 - For the TN802B only, this error type indicates that more
than three, but less than 9 DSPs are out of service (OOS), and a
WARNING alarm is raised. The Aux Data field contains the number of
DSPs that are Out Of Service (OOS).
d. Error Type 513 - For the TN2302 only, the port is out of service (OOS)
because an associated DSP is bad.
e. Error Type 515 - For the TN802B only, this error type indicates that all
DSPs are out of service (OOS), and a MINOR alarm is raised. The Aux
Data field contains the number of DSPs that are Out Of Service (OOS).
f. Error Type 1025 - The port is out of service (OOS) because of a board
level failure. Check for errors/alarms against the board; in particular, ping
problems, IP address inconsistency, or board sanity problems.
1. Verify correct administration.
2. Check cabling and customer network before replacing circuit pack.
258(c) ANY DSP Capacity Test
(#1382)
WARNING ON test board UUCCSS l r5
513(d) DSP Capacity Test
(#1382)
MINOR ON test port UUCCSSpp
515(e) ANY DSP Capacity Query
Test (##1382)
MINOR ON test board UUCCSS l r5
769 Any TDM NIC
Looparound Test
(#1380)
MIN ON test port UUCCSS l r10
1025(f) Any
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
Table 10-405. MEDPROPT Error Log Entries — Continued
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
Continued on next page
