MODEM-PT (Modem Pool Port)
Issue 4 May 2002
10-1101555-233-123
Hardware Error Log Entries and Test to Clear
Val ues
Note:
a. This error type indicates that the circuit pack has been removed or has
been insane for more than 21 minutes. To clear the error, reinsert or
replace the circuit pack.
System Technician-Demanded Tests: Descriptions
and Error Codes
Always investigate tests in the order presented in the table below when inspecting
errors in the system. By clearing error codes associated with the Modem Pool
Conference Test, for example, you may also clear errors generated from other
tests in the testing sequence. The tests in this section do not apply to Combined
Modem Pool conversion resources. The standard Digital Line and/or Analog Line
port tests are run on the ports associated with the Combined Modem Pool. The
test descriptions for those maintenance objects (MOs) should be consulted when
repairing Combined Modem Pool arrangements.
Modem Pool Port Error Log Entries
Error
Type
Aux
Data Associated Test Alarm Level
On/Off
Board Test to Clear Value
0
1
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
0 Any Any Any test port PCSSpp sh r 1
18 0 busyout PCSS WARNING OFF release port PCSSpp
130 (a) None WARNING ON test port PCSSpp sh
257 Conversion Resource
Loop Test (#98)
MINOR ON test port PCSSpp sh r 3
513 Modem Conference
Test(#97)
MINOR ON test port PCSSpp l r 3
769 Modem NPE
Crosstalk Test (#96)
MINOR ON test port PCSSpp l r 3
