PR-MAINT (Maintenance Processor [TN2404/TN790
RISC Systems])
Issue 4 May 2002
10-1367555-233-123
Notes:
a. The MTP Reset Test (#101) has failed.
b. The MTP Sanity Handshake Test (#106) has failed.
c. The MTP Analog Loop Around Test (#103) has failed.
d. The MTP Dual Port Ram Test (#104) has failed. An error of 769 with an aux
data of 5 indicates a hardware problem and testing cannot clear it. Replace
the circuit pack.
e. The MTP Outpulse Relay Test (#102) has failed.
f. The MTP SAT Loop Around Test (#228) has failed.
g. The MTP Aux Loop Around Test (#229) has failed.
h. The External Modem Present Test (#230) has failed.
NOTE:
Refer to the FAIL section of each test that fails for further instructions.
1537(f) Any MTP SAT Loop Around
Test (#228)
MIN ON test processor a/b r 3
1793(g) Any MTP Aux Loop Around Test
(#229)
MIN ON test processor a/b r 3
2049(h) Any External Modem Present
Test (#230)
MIN OFF test processor a/b r 2
1 The MTP Reset Test (#101) logs you off. The MTP Dual Port Ram Test (#104) can also log you off.
Manually repeat the command with the “long” option for the designated number of times when
testing from the PPN SAT.
2 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
Table 10-505. PR-MAINT Error Log Entries — Continued
Error
Type
Aux
Data Associated Test
Alarm
Level
On/Off
Board Test to Clear Value
1
Continued on next page
