Maintenance Object Repair Procedures
555-233-123
10-1444 Issue 4 May 2002
There are instances where the service state of a station is mentioned. The
different service states that apply to a remote digital line station are as follows:
Downloading of Terminal Parameters
Programmable Terminals
The following information describes how maintenance software interacts with
terminal parameter downloading.
Terminal Types:
a. 84xx multibutton digital voice terminals (8403D01A, 8410B, 8410D02A,
8434D01A) with optional expansion module.
b. 603A1 and 603D1 Callmaster terminals for telemarketing applications.
c. 302B1 and 302C1 attendant console.
Table 10-547. Remote Digital Line Station Service States
Out-of-Service The port, and thus the station, have been removed from service.
Busyout puts the port in the out-of-service state.
Ready-for-
Service
The port on the circuit pack has been put into service, but the voice
terminal has not yet established signaling communications with the
port.
In-Service The voice terminal has established signaling communications with
the port, and the system is ready to process calls to and from that
station. A terminal in the ready-for-service state will progress to the
in-service state if it is functioning normally. It can also be forced into
the in-service state by going off-hook.
