SHDW-LNK (Memory Shadowing Link)
Issue 4 May 2002
10-1509555-233-123
2049
(cont’d.)
FAIL Refer to the “Replacing Defective SPE Circuit Packs” section in
Chapter 6 to understand how to correctly replace the
Duplication-Interface circuit pack.
■ If none of the four red LEDs are lit AND if this is the first
attempt to clear the problem, replace the Standby SPE
Processor circuit pack as described in Chapter 6 and
proceed with Steps 9, 10, and 11.
■ If none of the four red LEDs are lit AND if this is the
second attempt to clear the problem (that is, the Standby
SPE Processor circuit pack has already been replaced),
replace the Standby SPE Memory circuit pack as
described in Chapter 6 and proceed with Steps 9, 10, and
11.
■ If none of the four red LEDs are lit AND if this is the third
attempt to clear the problem (that is, the Standby SPE
Processor and Standby SPE Memory circuit packs have
already been replaced), replace the Standby SPE
Duplication Interface circuit pack as described in Chapter
6 and proceed with Steps 9, 10, and 11.
■ If none of the four red LEDs are lit AND if this is the fourth
attempt to clear the problem (that is, the Standby SPE
Processor, Standby SPE Memory, and Standby SPE
Duplication Interface circuit packs have already been
replaced), replace the Active SPE Duplication Interface
circuit pack as described in Chapter 6 and proceed with
Steps 9, 10, and 11.
NOTE:
The Duplication Interface circuit pack must be made to
reside in the Standby SPE before it can be replaced.
Table 10-572. TEST #318 Shadow Link Test — Continued
Error
Code
Tes t
Result Description/Recommendation
Continued on next page
