Maintenance Object Repair Procedures
555-233-123
10-1542 Issue 4 May 2002
Table 10-578. Test Result Error Codes Associated with the Standby SPE
Error
Code
Tes t
Result Description/Recommendation
4 ABORT The Active SPE was unable to disable or enable shadowing from
Active SPE memory to Standby SPE memory. The communication
path between the Active SPE and the carrier A Duplication Interface
circuit pack may have failed, or the carrier A Duplication Interface
circuit pack may have failed.
1. Check for Active SPE Maintenance/Tape Processor errors and
alarms. Refer to PR-MAINT (Maintenance/Tape Processor)
Maintenance documentation and follow the prescribed
procedures.
2. Check for carrier A Duplication Interface circuit pack errors and
alarms. Refer to DUPINT (Duplication Interface Circuit Pack)
Maintenance documentation and follow the prescribed
procedures.
3. If the B carrier contains the Active SPE, check the Inter-Carrier
Cable to see if it is loose or disconnected. If so, follow the repair
procedures for connecting the Inter-Carrier Cable described in
Chapter 6, ‘‘Reliability Systems: A Maintenance Aid’’.
4. If all problems found in Steps 1, 2, and 3 have now been
repaired, proceed with Step 7. If no problems were found in
Steps 1, 2, and 3, proceed with Step 5.
5. Issue display errors and check to see if an Error Type 80 is
logged against STBY-SPE. If so, the problem is the carrier A
Duplication Interface circuit pack. Replace the carrier A
Duplication Interface circuit pack as described in Chapter 6,
‘‘Reliability Systems: A Maintenance Aid’’ and proceed with
Steps 7, 8, and 9.
Continued on next page
