Maintenance Object Repair Procedures
555-233-123
10-1754 Issue 4 May 2002
2000 FAIL Response to the seizure message was not received within the
allowable time period.
1. Enter list configuration board UUCSS . If the circuit pack
is a TN767B vintage 8 or 9, a failure of test 136 causes a
subsequent failure of test 7 due to a firmware bug.
Eventually, the board and all of its ports will be taken out of
service and extraneous on-board alarms will be generated.
Replace the circuit pack with a TN767C V3 or later.
2. Verify that the ’Trunk Type’ field on the ’Trunk
Administration’ screen matches the trunk type administered
on far-end switch.
3. Look for DS1-BD or UDS1-BD errors in the hardware error
log. If present, refer to the DS1-BD (DS1 trunk circuit pack)
Maintenance documentation or to the UDS1-BD (UDS1
trunk circuit pack) Maintenance documentation.
4. Retry the test at 1-minute intervals for a maximum of 5
times.
PASS The trunk can be seized for an outgoing call.
0NO
BOARD
The test could not relate the internal ID to the port (no board).
This could be due to incorrect translations, no board is inserted,
an incorrect board is inserted, or an insane board is inserted.
1. Check to ensure that the board translations are correct.
Use list config , and resolve any problems that are found.
2. If the board was found to be correctly inserted in step 1,
issue the busyout board command.
3. Issue the reset board command.
4. Issue the release busy board command.
5. Issue the test board long command. This should
re-establish the linkage between the internal ID and the
port. If this is not the case, check to see that there is a valid
board inserted.
1 Earlier G1 Software Versions reported Error Code 2053 as a FAIL
Table 10-645. TEST #136 DS1 Tie Trunk Seizure Test — Continued
Error
Code
Te s t
Result Description/Recommendation
Continued on next page
