Maintenance Object Repair Procedures
555-233-123
10-1994 Issue 4 May 2002
DEFINITY PBX) via the dedicated fractional T-1. All Wideband Access Endpoint
functionality and operation is identical on both line-side and network facilities.
However, because maintenance capabilities are limited to the Wideband Access
Endpoint interface, and because faults can occur end-to-end, troubleshooting
procedures based on an end-to-end view of the network is required.
Wideband Access Endpoint Port maintenance provides a strategy for maintaining
a Wideband Access Endpoint Port via a port on the Universal DS1 interface circuit
pack hardware. The maintenance strategy involves logging Wideband Access
Endpoint Port hardware errors, running tests for port initialization, periodic and
scheduled maintenance, system technician-demanded tests, and alarm
escalation and resolution. Two different port service states are specified in the
Wideband Access Endpoint Port maintenance. These states include
out-of-service, where the port is in a deactivated state and cannot be used for
calls, and in-service, where the port is in an activated state and can be used for
calls. If the Universal DS1 Interface circuit pack (TN464C) is out-of-service, all
ports on the Universal DS1 Interface circuit pack (TN464C) are placed into the
out-of-service state.
Hardware Error Log Entries and Test to Clear
Val ues
Wideband Access Endpoint Maintenance Error Log Entries
Error
Type
Aux
Data Associated Test Alarm Level
On/Off
Board Test to Clear Value
0
1
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
0 Any Any Any test access-endpoint
<extension> sh r 1
18 (a) 0 busyout
access-endpoint
WARNING OFF release access-endpoint
<extension>
130 (b) None WARNING ON test access-endpoint
<extension>
1281 (c) Conference Circuit
(Test #7)
MINOR ON test access-endpoint
<extension> l r 4
1537 (d) NPE Crosstalk Test
(#6)
MINOR ON test access-endpoint
<extension> l r 3
1793 (e) None test board PCSS long
3840 (f) Any Port Audit and
Update (Test #36)
