Maintenance Commands and Trouble-Clearing Aids
555-233-123
8-80 Issue 4 May 2002
Form output
After completing the options screen, the system displays a 1- or 2-page Hardware
Error Report. To toggle between the pages and to exit the report, use the keys
described below:
■ For 513 and 715 terminals, use F8 for NEXT PAGE and PREV PAGE
commands
■ For all other terminals, use F7 for NEXT PAGE and PREV PAGE commands
■ Use Esc for the CANCEL command to exit the report.
The figure below is an example of an Hardware Error Report -- Active Alarms,
without the high-resolution qualifier in the command line.
Field descriptions
Port
Lists the location codes for the alarmed object, as follows:
■ Circuit packs locations: cabinet-carrier-[slot]-[circuit].
Example: 01C702.
■ Port network locations: port network number-bus. Example:
PN 02B. PN 02 = Port Network (PN) number and A or B =
bus.
Maintenance
Name
The name of the maintenance object.
Alt Name
Identifies the location of maintenance object, as follows:
■ Station = extension number
■ Trunk = Group number (78/__) or group and member
numbers (78/01)
■ Private CO Line = private CO line (P) and group number
(P/xxx)
display errors Page 1 SPE A
HARDWARE ERROR REPORT - ACTIVE ALARMS
Port Mtce Alt Err Aux First Last Err Err Rt/ Al Ac
Name Name Type Data Occur Occur Cnt Rt Hr St
01C0702 ANL-LINE 311 257 01/31/09:20 01/31/20:26 255 256 255 a y
01C0701 ANL-LINE 1051 257 01/31/20:26 01/31/20:26 4 0 4 a y
01C0703 ANL-LINE 1053 257 01/31/20:26 01/31/20:26 4 0 4 a y
01A TDM-CLK 0 0 01/31/20:34 01/31/20:34 1 0 1 a n
01C1505 CO-TRK 078/001 3329 57408 01/31/20:26 01/31/20:27 5 300 5 a y
01C1505 CO-TRK 078/001 1537 01/31/20:26 01/31/20:28 5 150 5 a y
02A0201 TONE-PT 0 01/31/20:34 01/31/20:34 1 0 1 a y
PN 02B TDM-BUS 18 0 01/31/14:53 01/31/21:12 1 0 1 a n
Command successfully completed
