Maintenance Commands and Trouble-Clearing Aids
555-233-123
8-202 Issue 4 May 2002
General
0x71 - GAP marker
GAP reasons:
0x01 - disabled, disable mst command executed
0x02 - disabled, mst timer expired
0x03 - disabled, buffer full on no-wrap
0x04 - disabled, restart occurred
0x05 - disabled, by stop trigger or count
0x06 - disabled, audit error
0x07 - not disabled, stopped by stop trigger or count
0x72 - Time changed while trace enabled
timestamp indication:
0x00 - MST timestamp is old time
0x01 - MST timestamp is new time
X.25 Application Data
The processor channel number is the R1/R3 term, and R2 calls it the port number.
The processor channel number is equal to the Application port number in R1. In
R3, the processor channel admin screen should be inspected to determine the
mapping.
Message[1] = GAP reason
Message[2] = GAP count (since last clear - high byte)
Message[3] = GAP count (since last clear - low byte)
Message[1] = 0x00
Message[2] = timestamp indication
