Maintenance Commands and Trouble-Clearing Aids
555-233-123
8-402 Issue 4 May 2002
The following display shows a typical result when status trunk 1/19 is entered.
For an ip-TDM call, the audio switch port field shows one of ports 1-8 on a
TN2302 Prowler board.
status trunk 1/19 SPE B
TRUNK STATUS
Trunk Group/Member: 01/19 Service State: in-service/active
Port: T00123 Maintenance Busy? no
Signaling Group ID: 1 CA-TSC state: not allowed
MM Conference ID: 8
MM Endpoint ID: 2
Connected Ports: 01B1431 01C1008
S00004
Switch IP IP
Port Near-end IP Addr: Port Far-end IP Addr : Port
Q.931: 12B1217 xxx.xxx.xxx.xxx : nnnnn xxx.xxx.xxx.xxx : nnnnn
H.245: 12B1217 xxx.xxx.xxx.xxx : nnnnn xxx.xxx.xxx.xxx : nnnnn
G.711-MU Audio: 12B1108 xxx.xxx.xxx.xxx : nnnnn xxx.xxx.xxx.xxx
: nnnnn
H.245 Tunneled in Q.931? no
Audio Connection Type: ip-tdm
status trunk 1/19 SPE B
TRUNK STATUS
Trunk Group/Member: 01/19 Service State: in-service/active
Port: T00123 Maintenance Busy? no
Signaling Group ID: 1 CA-TSC state: not allowed
MM Conference ID: 8
MM Endpoint ID: 2
Connected Ports: S00004
Switch IP IP
Port Near-end IP Addr: Port Far-end IP Addr : Port
Q.931: 12B1217 xxx.xxx.xxx.xxx : nnnnn xxx.xxx.xxx.xxx : nnnnn
H.245: 12B1217 xxx.xxx.xxx.xxx : nnnnn xxx.xxx.xxx.xxx : nnnnn
G.711-MU Audio: 12B11 xxx.xxx.xxx.xxx : nnnnn xxx.xxx.xxx.xxx
: nnnnn
H.245 Tunneled in Q.931? no
Audio Connection Type: ip hairpin
