ANN-BD (Announcement Circuit Pack)
Issue 4 May 2002
10-137 555-233-123
!
WARNING:
Announcement board alarms are upgraded to MAJOR when the BASE Tone
Generator is set to 12. (France).
Notes:
a. Error Type 1
The circuit pack totally stopped functioning or it was
physically removed from the system.
NOTE:
The alarm is logged about 11 minutes after the circuit pack has been
removed and/or SAKI Test (#53) fails.
If the circuit pack is not in the system, insert a circuit pack (in the same slot
as the error indicates) to resolve this error. Or, if the circuit pack is in the
system and the red LED is on, follow the instructions for “Red (alarm)” in
the “Control and Port Circuit Pack Status Led” section in Chapter 7, “LED
Interpretation”.
NOTE:
The alarm is logged about 11 minutes after the circuit pack has been
removed and/or SAKI Test (#53) fails.
2561 Super Frame
Match Inquiry
Test (#211)
MINOR ON test board PCSS sh r 3
17676 In-line Error
2817(l) Announcement
Checksum Test
(#209)
MINOR ON test board PCSS sh r 3
17682 In-line Error
17699
(m)
In-line Error
3840(n) Any None
3999(o) Any None
1 Run the Short Test Sequence first. If all tests pass, run the Long Test Sequence. Refer to the
appropriate test description and follow the recommended procedures.
Table 10-44. Announcement Circuit Pack Error Log Entries — Continued
Error
Type
Aux
Data
Associated
Te s t
Alarm Level
(See WARNING
below)
On/
Off
Board Test to Clear Value
Continued on next page
To Next Page
