Engine
SHOP MANUAL
Ch 1 page 63
13. It is easier to position the slide hammer if one
of the lower rocker cover bolts is removed.
14. Withdraw the unit injector. If the unit injector
is stuck, tap carefully with a rubber mallet on
the solenoid valve housing.
15. Remove the sealing washer from the bottom
of the injector seat, (if it was left behind
when the unit injector was removed).
16. Detach the intake manifold, fuel manifold,
ventilation pipe for the cooling system and
the exhaust manifold.
17. Remove the cylinder head. Mark the cylinder
heads if more than one is being removed at
the same time.
The unit injector is not to be dismantled. Renew the entire unit.
NOTE
Figure 106
Figure 105
