SHOP MANUAL
TRANSMISSION
Ch 2 page 24 Ch 2 page 25
TRANSMISSION
Remove the clamp of the hinge bearing lubrication from the body heat-
ing bracket.
Disassemble the body
heating (if it is assembled
on machine) 04 screws in
the body heating bracket.
Remove 04 screws in
pipe clamps attached to
exhaust pipe.
Remove the A/C gas.
Remove body heating assembly.
Figure 14
Figure 15
Figure 16
Figure 17
Figure 18
CAUTION
A/C pressure, remove carefully
