SHOP MANUAL
TRANSMISSION
Ch 2 page 32 Ch 2 page 33
TRANSMISSION
Check around the transmission that all connections
to the front frame equipment not are connected to the
transmission.
Assemble the lifting device and adjust the chains to keep
the transmission in balance. start lifting the transmission
out of the frame.
Carefully !
Be aware that the transmission have to be moved front-
wards and twisted to the right side on front. In this posi-
tion carefully lift up the transmission.
Be specially aware of the transmission differential otput
flange and the back side.
Pay attention on the length of chains.
Use 03 chains to hang the T/M on the 03 eye bolts.
Figure 51
Figure 52
