SHOP MANUAL
TRANSMISSION
Ch 2 page 44 Ch 2 page 45
TRANSMISSION
Preload all follow-on slides (see arrow) and remove the stop
plates (1).
Remove all follow-on slides consisting of:
• piston (1)
• compression spring (2).
Disengage the retaining ring (1).
Remove the pressure reducing valve consisting of:
• plug (1)
• compression spring (2)
• piston (3).
1
1
2
1
3
1
2
Figure 91
Figure 90
Figure 89
Figure 92
