SHOP MANUAL
TRANSMISSION
Ch 2 page 42 Ch 2 page 43
TRANSMISSION
Remove wiring harness (1).
Loosen the cylindrical screw (2) of the dierential lock solenoid
valve.
Remove the dierential lock solenoid valve (1) with bracket (2).
Loosen the duct plate/valve block screw connection (3).
Remove the cylindrical screws (4) from the clamping plates.
Remove valve block (1) and seal (2).
Remove screw plugs with O-ring (3).
Remove all pressure controllers (1) with their clamping plates
(2).
2
1
2
1
3
4
1
3
1
2
2
Figure 86
Figure 85
Figure 88
Figure 87
