SHOP MANUAL
DRIVE LINE
Ch 3 page 24 Ch 3 page 25
DRIVE LINE
1
By means of the lifting tackle separate t
he hub carrier (1) from axle casing.
(S) Lifting strap 514655
By means of the lifting tackle separate the
brake carrier (1) from the axle casing.
(S) Eyebolts assortment 504182
(S) Lifting chain 505762
Figure 42
Figure 41
Figure 43
