SHOP MANUAL
DRIVE LINE
Ch 3 page 98 Ch 3 page 99
DRIVE LINE
Pre-assemble Differential (Figure 271 ... 283)
Insert thrust washer, with the chamfer on the outer diameter show-
ing downward, into the differential housing.
Introduce side gear until both inner plates are accommodated.
Introduce thrust ring.
Install plate pack A, starting with one outer plate.
Pay attention to the Note, Figure 269 Previous Page!
Lubricate the differential components according
to ZF-List of lubricants TE-ML 05 (with LS-Addi-
tive) !
NOTE
NOTE
Figure 274
Figure 273
Figure 272
Figure 271
To Next Page
