SHOP MANUAL
DRIVE LINE
Ch 3 page 142 Ch 3 page 143
DRIVE LINE
With differential housing in secure position. Reassemble the
two rear axle adapters.
Apply locking liquid on bolt threads: locktite 245
Tighten bolts M20
Torque: 574 Nm
Figure 433
Reassemble articulation bearing to differential house
adapter.
Tighten torque: 649 Nm
Figure 435
Figure 434
Assemble the outer screws for the articulation bearing, connecting
bearing to tandem house.
28 pcs. M20
Figure 436
