SHOP MANUAL
DRIVE LINE
Ch 3 page 154 Ch 3 page 155
DRIVE LINE
Be aware of personal injury
Clean and oil the surfaces on the distance ring
Assemble the slide seal ring into the wheel axle distance ring
Clean the axle and apply oil before assemble
the bearing.
500 KG
Use tube to press the bearing in position.
Hold press on the tube to the bearing temperature is cool down
Be aware of personal injury
WARNING
WARNING
Figure 467
Figure 466
Figure 465
To Next Page
