SHOP MANUAL
DRIVE LINE
Ch 3 page 154 Ch 3 page 155
DRIVE LINE
Be aware of personal injury
Clean the wheel axle and apply oil the surface
Assemble the preassembled distance ring
With plastic mallet knock carefully on the ring
Clean the surfaces
Assemble the outer bearing.
Clean the axle and apply oil before assemble the
bearing.
Heat the inner diameter of the bearing v\with elec-
trical heater, Hot oil or Hot air blower
Temp 75 - 120°C
(167 - 248°F)
(S) Hot-air blower 230 V 504193
(S) Hot-air blower 115 V 504194
WARNING
Figure 463
Figure 462
Figure 461
Figure 464
