DRIVE LINE
Preassemble the distance ring (3):
Insert the O-ring (2) and oil the surface.
Pre-assemble the wheel axle
Assembly the wheel bolts.
Use hydraulic press or sledgehammer.
Apply sealing compound and Insert the hexagon screw plug
(Set screw M12x10 ISO 4029)
into the distance ring.
Check up that the screw plug is not coming out of the
threaded hole
Be aware of personal injury Use safety glasses
and be aware of ying objects
