SHOP MANUAL
DRIVE LINE
Ch 3 page 152 Ch 3 page 153
DRIVE LINE
Remove the disc plate (9 pcs)
When remove the return mechanism, knock down the slot
pin and remove the lock ring.
Lift out the return mechanism
Remove the piston, use compressed air into the oil line to lift
the piston up.
Use hook or similar to take the piston from the hub.
Remove the old and worn packing ring
Clean the hub and reusable parts.
Figure 456
