Doosan DA40 - Page 531

SHOP MANUAL
DRIVE LINE
Ch 3 page 168 Ch 3 page 169
DRIVE LINE
2)
With no press,
rotate the hub
housing 20 times
3)
Check the rolling resis-
tance.
Example, resistance:
8 - 17 Nm.
At this stage, no preload
on the bearing.
(Free spinning)
1)
Assemble the gear wheel to contact with the bearing inner ring.
Do not press!
NOTE
NOTE
2
Figure 502
