Doosan DA40 - Page 594

SHOP MANUAL
HYDRAULIC
Ch 5 page 14 Ch 5 page 15
HYDRAULIC
Posion Descripon Part no. Head/socket Torque
20 Check valve 8mm! * 10Nm
* Make sure 8mm socket facing outside of port!
Posion Descripon Part no. Head/socket Torque
3 Relief valve 10mm 60Nm
Seal Kit
Posion Descripon Part no. Head/socket Torque
4,5 Check valve 22mm 40Nm
Seal Kit
Posion Descripon Part no. Head/socket Torque
33 Proporonal reducing valve 7/8” (22,2mm) 30Nm
Coil 3/4” (19,0mm) 3,5Nm
Seal Kit
Posion Descripon Part no. Head/socket Torque
18 Shule valve 6mm 10Nm
Seal Kit + Locking uid
Posion Descripon Part no. Head/socket Torque
29,34
Proporonal reducing
valve 3mm (2x) 3Nm
Orice cap Ø1,2mm (set
of 5pcs)
Snap to end of reducing
valve!
Seal Kit
Posion Descripon Part no. Head/socket Torque
21 Solenoid valve 7/8” (22,2mm) 30Nm
Coil 3/4” (19,0mm) 3,5Nm
Seal Kit
Posion Descripon Part no.
55
Flange half
50 Tilng valve
Posion Descripon Part no. Head/socket
46 Flange half
47 Screw
Posion Descripon Part no. Head/socket Torque
44
Flange half
60 Screw Screw M12
