Ch 6 page 13
ELECTRICAL SYSTEM
SHOP MANUAL
Pos. No Circuit and
place ref.
Map No. Description VCU2 text (circuit diagram)
143 2- A4 Accumulator2 Rear brake
144 2- B4 Accumulator3 Park brake
145 2- B4 A (body lift)
146 2- B4 Park brake
147 2- B4 Emergency steering
160 2- C4 Ambient
161 2- C4 Front hubs
162 2- C4 Hydraulic tank
170 2- C4 WDB tank level
171 2- D4 Emergency stop switch
172 2- K4 Expansion tank level
173 2- K4 Air filter sensor
180 2- D4 Body tip up
181 2- D4 Body tip down
182 2- E4 Fan drive
183 2- E4 Engine exhaust brake
190 2- E4 Brake charge valve
191 2- E4 Park brake valve
192 2- F4 Float valve
193 2- F4 Rear diff lock valve
194 2- F4 Fan stop valve
195 2- G4 Fan reverse
200 2- H5 Fuel tank level sensor
201 2- H5 Hydraulik tank
202 2- I4 EP400 oil level sensor
205 2- I5 Fan sped sensor
210 2- J5 Scania S8
211 2- K5 Scania SCR
212 2- E15 Engine fuel heater
220 2- L5 ZF EC2 EP400
221 2- M5 Filter restriction switch (Transm.)
230 2- H10 Sentral lubrication GW Twin-3 Can
303 2- A10 RH mirror arm low beam
304 2- A10 RH mirror arm work light
305 2- A10 RH upper mirror
306 2- B10 RH lower mirror
307 2- B10 RH mirror arm direction light
307 2- B10 RH mirror arm mark light
