SHOP MANUAL
Ch 6 page 14
ELECTRICAL SYSTEM
Pos. No Circuit and
place ref.
Map No. Description VCU2 text (circuit diagram)
310 2- B9 RH front direction light
311 2- C9 RH high/low beam
323 2- D10 LH mirror arm low beam
324 2- D10 LH mirror work light
325 2- D10 LH upper mirror
326 2- D10 LH lower mirror
327 2- E10 LH direction light
327 2- E10 LH mirror arm mark light
330 2- E9 LH front direction light
330 2- E9 LH park light
331 2- F9 LH high / low beam
340 2- E11 Signal horn (LH side)
341 2- F11 Signal horn (RH side)
350 2- G10 AC compressor clutch
400 2- H10 Lubrication pressure sensor
410 2- J11 RH brake & rear direction & tail light
411 2- J11 LH brake & rear direction & tail light
412 2- J10 License plate light
413 2- J10 RH rear work light
414 2- J10 LH rear work light
415 2- K10 Reverse alarm
420 2- L11 WB2T (or RU1)
421 2- M10 RH tandemtemperature
422 2- M10 LH tandem temperature
423 2- K10 BU1
424 2- M10 Body down sensor
430 1- I11 Rear camera
