Ch 6 page 15
ELECTRICAL SYSTEM
SHOP MANUAL
D1 1- J9 Diagnostics
D2 1- G8 LCD USB connector
F1 2- B15 Main fuse 100a
F2 2- B15 Secondary Fuse 15A
F3 2- D15 Secondary Fuse 20A
K1 2- E14 Engine heater relay
S1 3C 3C Cab split- Deutch HDP20
S2 3C 3C Cab split- Deutch HDP20
S3 3C 3C Cab split- Deutch HDP20
S4 3C 3C Cab split- Deutch HDP20
S5 3C 3C Cab split- Deutch HDP20
S6 3C 3C Cab split- Deutch HDP20
S44 3B Harnes split for LCD unit
S55 3C 3C Harnes split
S57 3B Harnes split
S70 3C 3C Split
S71 3C 3C Split
S72 3C 3C Split
S75 3C 3C Harness split
S76 3C 3C Harness split
S77 3C 3C Harness split
S96 3C 3C Harness split
S97 3C 3C Harness split
S98 3C 3C Harness split
S22O 2- M3 EP400 filter sensor
X1-23 3C 3C
Pos. No Circuit and
place ref.
Map No. Description VCU2 text (circuit diagram)
