Variables and Commands CDHD
112 VarCom Reference Manual
GEARIN
Definition Gear Ratio Multiplier
Type Variable (R/W)
Description Gets/sets the numerator of the gearbox equation.
The gearing relationship is as follows:
(GEARIN/GEAROUT) ×(1/XENCRES)
Gearing sets up a relationship between the number of input
pulses (HWPEXT counts) and the position increments of the
motor shaft (or actual motor position, PFB).
The rate at which position increments of the motor shaft
(motor speed) occur is determined by the gearing
relationship and the line frequency of the pulse train.
The direction of rotation is determined by the sign of the
variable GEARIN.
Syntax Read: GEARIN
Write: GEARIN <value>
Firmware 1.0.6
Drive status Disabled
Range ±32767
Default value 1
Unit Not Applicable
Non-volatile Yes
See also GEARMODE
GEAROUT
