Variables and Commands CDHD
302 VarCom Reference Manual
OUTPLVL2
Definition Position Level 2 for Digital Output Definition
Type Variable (R/W)
Description Gets/sets the second position level used for a condition that
controls a digital output.
Syntax Read: OUTPLVL2
Write: OUTPLVL2 <value>
Firmware 1.0.6
Drive status Enabled | Disabled
Range ±(2
31
1) [rev]
Default value 0
Unit If MOTORTYPE 0 (Rotary):
UNITSROTPOS 0 = rev
UNITSROTPOS 1 = count
UNITSROTPOS 2 = deg
UNITSROTPOS 3 = user-defined multiples of
revolutions (PNUM÷PDEN)
If MOTORTYPE 2 (Linear):
UNITSLINPOS 0 = pitch
UNITSLINPOS 1 = count
UNITSLINPOS 3 = mm
UNITSLINPOS 4 = user-defined multiples of pitch
(PNUM÷PDEN)
Non-volatile Yes
See also OUTINV
OUTMODE
OUTPLVL1
OUTPUTS
CANopen 209Eh, sub-index 0
