CDHD Variables and Commands
VarCom Reference Manual 43
ANOUTISCALE
Definition Analog Output Current Scaling
Type Variable (R/W)
Description Gets/sets the scaling of the analog output voltage that
represents the motor current (I) or the current command
(ICMD).
For example, if ANOUTMODE=4 (current command
monitoring): ANOUT [V] = ICMD [A] ÷ ANOUTISCALE [A/V]
Syntax ANOUTISCALE
Firmware 1.0.6
Drive status Enabled | Disabled
Range 0 to 10
Default value 0
Unit A/V
Non-volatile Yes
See also ANOUT
ANOUTLIM
ANOUTMODE
