CDHD Variables and Commands
VarCom Reference Manual 347
RECTRIGLIST
Definition Recording Trigger Variables List
Type Variable (R)
Description Returns a list of all trigger variables and options.
The recording trigger is defined by RECTRIG.
The variables listed below are the most commonly used
trigger sources. To view the complete list of trigger variables,
issue the command to the drive.
Note: Some factory variables and commands, not intended
for users, may appear in the list.
Do not attempt to use commands and variables that are
not described in this manual, or are marked as not for
users.
Syntax RECTRIGLIST
Firmware 1.0.6
Drive status Enabled | Disabled
Range Dynamic signal variables:
ANIN1
ANIN2
ANOUT
CLVD
CLVQ
ELECTANGLE
FOLD
HWPEXT
I
ICMD
ID
IFOLD
ILIMACT
IN (IN1 – IN11)
IQ
IQCMD
IU
IV
MECHANGLE
MFOLD
MIFOLD
OUT (OUT1– OUT7
PCMD
PE
PELOOP
PFB
PTPTE
PTPVCMD
REMOTE
STOPPED
THERM
V
VBUSREADOUT
VCMD
VE
Status variables:
ACTIVE
HOMESTATE
LIMSWITCHNEG
LIMSWITCHPOS
Default value Not Applicable
Unit Not Applicable
Non-volatile No
See also RECTRIG
