Variables and Commands CDHD
38 VarCom Reference Manual
ANIN2MODE
Definition Analog Input 2 Mode
Type Variable (R/W)
Description Gets/sets a value that defines the function of analog input 2.
Syntax Read: ANIN2MODE
Write: ANIN2MODE <value>
Firmware 1.0.6
Drive status Disabled
Range -1= Hardware defined dual gain. ANIN2 is inactive, ANIN1
has a 16 bit resolution, ANIN2MODEis read only.
0 = Idle. ANIN2 input voltage is read only.
1 = Dual gain - external jumper connection between the
analog inputs is required.
2 = Current limit mode - second input limits current
command (uses ANIN2ISCALE)
Note: Make sure hardware matches this configuration.
Default value 0
Unit Not Applicable
Non-volatile Yes
See also ANIN2
ANIN2ISCALE
