Servotronix CDHD - Menctype

Variables and Commands CDHD
218 VarCom Reference Manual
MENCTYPE
Definition Motor Encoder Type
Type Variable (R/W)
Description Gets/sets the motor encoder type.
Incremental encoders: 0, 1, 2, 3, 4, 6, 11
Sine encoders: 1, 2, 3, 4
When the value of MENCTYPE is changed, CONFIG is
required.
Syntax Read: MENCTYPE
Write: MENCTYPE <value>
Firmware 1.0.6
Drive status Disabled
Range
FEEDBACKTYPE MENCTYPE
Resolver 1 NA
Incremental Encoder A/B/Z/H 2 0
Incremental Encoder A/B/Z Init by
PHASEFIND command
2 1
Incremental Encoder A/B/Z Init by ENABLE
and PHASEFIND command
2 2
Incremental Encoder A/B Init by PHASEFIND
command
2 3
Incremental Encoder A/B Init by ENABLE and
PHASEFIND command
2 4
Incremental Encoder A/B/H 2 6
Sine Encoder A/B/Z/H 3 0
Sine Encoder A/B/Z Init by PHASEFIND
command
3 1
Sine Encoder A/B/Z Init by ENABLE and
PHASEFIND command
3 2
Sine Encoder A/B Init by PHASEFIND
command
3 3
Sine Encoder A/B Init by ENABLE and
PHASEFIND command
3 4
Sine Encoder A/B/H 3 6
Endat 2.2 11 NA
Endat 2.1 with Sine Signals 3 9
Hiperface with Sine Signals 3 10
Nikon Encoder 17-bit ABS Single/Multi turn 4 NA
Tamagawa Incremental Encoder (8 wires) 2 11
Tamagawa Encoder 17-bit ABS Single Turn 7 NA
Tamagawa Encoder 17-bit ABS Multi Turn 6 NA
Default value 6
