Variables and Commands CDHD
116 VarCom Reference Manual
GEAROUT
Definition Gear Ratio Divider
Type Variable (R/W)
Description Gets/sets the denominator of the gearbox equation.
The gearing relationship is as follows:
(GEARIN/GEAROUT) ×(1/XENCRES)
Gearing sets up a relationship between the number of input
pulses (HWPEXT counts) and the position increments of the
motor shaft (or actual motor position, PFB).
The rate at which position increments of the motor shaft
(motor speed) occur is determined by the gearing
relationship and the line frequency of the pulse train.
Syntax Read: GEAROUT
Write: GEAROUT <value>
Firmware 1.0.6
Drive status Disabled
Range 1 to 32767
Default value 1
Unit Not Applicable
Non-volatile Yes
See also GEARIN
GEARMODE
