CDHD Variables and Commands
VarCom Reference Manual 409
VLIM
Definition User Velocity Limit
Type Variable (R/W)
Description Gets/sets the application velocity limit, allowing the user to
limit the motor’s peak velocity.
VLIM limits the velocity command that will be accepted from
the user (using the J command in OPMODE 0) or issued by
the control loops (in OPMODE 1). VLIM is an independent
variable that is not calculated from hardware parameters and
is not tied to any other variables. VLIM is similar to ILIM
(used in OPMODE 2 and OPMODE 3) and can be used to
protect delicate load equipment.
When the value of VLIM is changed, CONFIG is required.
Syntax Read: VLIM
Write: VLIM <value>
Firmware 1.0.6
Drive status Disabled
Range 0 to VMAX
Default value If MOTORTYPE 0 (Rotary):
UNITSROTVEL 0 = 16.667
UNITSROTVEL 1 = 1000.000
UNITSROTVEL 2 = 6000.000
UNITSROTVEL 3 = 83.333
If MOTORTYPE 2 (Linear):
UNITSLINVEL 1 = 533.333
UNITSLINVEL 2 = 16.667
Unit If MOTORTYPE 0 (Rotary):
If UNITSROTVEL 0 = rps
If UNITSROTVEL 1 = rpm
If UNITSROTVEL 2 = deg/s
If UNITSROTVEL 3 = user/s
If MOTORTYPE 2 (Linear):
UNITSLINVEL 1 = mm/s
UNITSLINVEL 2 = user/s
Non-volatile Yes
See also MSPEED
VMAX
CANopen 607Fh, sub-index 0
