Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-5
Error Messages and Codes
Messages, Chain Link Codes, and Procedures
The error messages and chain link codes generated by the printer’s operating
system are the lead-in to the troubleshooting procedures that follow in
subsequent pages. This section correlates the output of the printer’s
diagnostic aids and provides the troubleshooting procedures to locate and
correct the reported errors.
Error Messages Abbreviations
Due to limited display space, some error messages include abbreviations.
The most common abbreviations used throughout this chapter are listed here.
Term Definition
ADC Automatic Density Control
ASIC Application-Specific Integrated Circuit
BLK Black
COMM Communication
CRT Cartridge
CRUM Customer Replaceable Unit
ER/ERR Error
ENV Environment
FUNC Function
MACaddress Media Access Control Address
MCU Machine Control Unit
MPC Multi-Protocol Network Card
NVM Non-Volatile Memory. Used instead of NVRAM.
NVRAM Non-Volatile Random Access Memory
PCL Printer Control Language
PDL Page Description Language
RAM Random Access Memory
REG Registration
ROM Read Only Memory
TRAN Transfer Unit

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
