Phaser 6180MFP Multifunction Printer Service Manual 6-7
Adjustments and Calibrations
Saving NVM (NVRAM)
This process saves the settings stored in the NVRAM to the Image Processor
Board.
1. Access the Service Diagnostics menu by pressing and holding the Up
and Down Arrow buttons simultaneously and turn the printer power On.
2. The Service Mode is displayed. Select Printer Diag and press the OK
button.
3. Press the Up Arrow or Down Arrow button to find Engine Diag. Press
the OK button.
4. Press the Up Arrow or Down Arrow button to find NVM Settings. Press
the OK button.
5. Press the Up Arrow or Down Arrow button to find Save NVM to ESS.
Press the OK button.
6. SaveNVM to ESS - OK? message is displayed. Press the OK button to
start the process.
7. Processing > Saved message is displayed.
8. Press the Exit button three times to return to the Printer Diag menu.
Press the Up Arrow or Down Arrow button to find Exit Mode. Press the
OK button.
9. Complete Exit message is displayed. Press the OK button.
10. Exit? message is displayed. Press the OK button.
Loading NVM (NVRAM)
This process loads the NVM settings stored in the Image Processor Board.
1. Access the Service Diagnostics menu by pressing and holding the Up
and Down Arrow buttons simultaneously and turn the printer power On.
2. The Service Mode is displayed. Select Printer Diag and press the OK
button.
3. Press the Up Arrow or Down Arrow button to find Engine Diag. Press
the OK button.
4. Press the Up Arrow or Down Arrow button to find NVM Settings. Press
the OK button.
5. Press the Up Arrow or Down Arrow button to find LoadNVM from ESS.
Press the OK button.
6. LoadNVM from ESS - OK? message is displayed. Press the OK button
to start the process.
7. Processing > Loaded message is displayed.
8. Press the Exit button.
9. Please wait... message is displayed on the printer’s Control Panel.
10. NVM Settings... - LoadNVM from ESS menu is displayed.
11. Press the Exit button two times to return to the Printer Diag menu. Press
the Up Arrow or Down Arrow button to find Exit Mode. Press the OK
button.
12. Complete Exit message is displayed. Press the OK button.
13. Exit? message is displayed. Press the OK button.
14. Please wait... --> Ready messages are displayed on the printer Control
Panel.
