Phaser 6180MFP Multifunction Printer Service Manual 9-3
Parts List
Using the Parts List
■ ID No.: The callout number from the exploded part diagram.
■ Name/Description: The name of the part to be ordered and the number
of parts supplied per order.
■ Part Number: The material part number used to order that specific part.
■ Parts identified throughout this manual are referenced PL#.#.#; For
example, PL3.1.10 means the part is item 10 of Parts List 3.1.
■ A black triangle preceding a number followed by a parenthetical statement
in an illustrated parts list means the item is a parent assembly, made up of
the individual parts called out in parentheses.
■ The notation “with X~Y” following a part name indicates an assembly that
is made up of components X through Y. For example, “1 (with 2~4)”
means part 1 consists of part 2, part 3, and part 4.
■ An asterisk (*) following a part name indicates the page contains a note
about this part.
■ The notation (NS) next to a part indicates that particular part is not
spared, but contained in a kit or major assembly.
■ The notation “J1<>J2 and P2” is attached to a wire harness. It indicates
that connector Jack 1 is attached to one end of the wire harness and
connector J2 is attached to the other end that is plugged into P2.
o
e
Only parts showing part numbers are available for ordering by support.
Parts not showing part numbers are available on the parent assembly.
Abbreviations
Abbreviation Meaning
CC-ring
EE-ring
KL K-clip
S Screw
