Phaser 6180MFP Multifunction Printer Service Manual 3-53

Error Messages and Codes

Remove Print Cartridge Tape (Yellow/Magenta/Cyan/Black)

The Print Cartridge (Yellow/Magenta/Cyan/Black) tape was not removed

when a new Print Cartridge is installed. The following troubleshooting

procedure applies to these errors.

Applicable Chain Links

■ Chain Link 093-919: Check Yellow Cartridge

■ Chain Link 093-920: Check Magenta Cartridge

■ Chain Link 093-921: Check Cyan Cartridge

■ Chain Link 093-922: Check Black Cartridge

Initial Actions

■ Check the Print Cartridge life using CentreWare IS.

■ Cycle printer power.

■ If problem persists, follow the procedure below.

Troubleshooting Reference Table

Applicable Parts Wiring and Plug/Jack Map References

■ Print Cartridge (Y/M/C/K),

PL5.1.17-20

■ Dispenser, PL5.2.10

■ MCU Board, PL9.2.13

■ Top LV Harness, PL10.1.3

■ “Map 3 - Image Processor Board and

Dispenser Motors” on page 10-12

■ “Map 4 - LVPS and MCU Board” on

page 10-13

■ “Developer” on page 10-38

Troubleshooting Procedure Table

Step Actions and Questions Yes No

1 Check the Print Cartridge tape. Has the

tape been removed?

Go to step 2. Remove the

tape on the

Print Cartridge.

Go to step 2.

2 Does the error still occur? Go to step 3. Complete.

3 1.Replace the Print Cartridge

(page 8-11).

2.Does the error still occur?

Go to step 4. Complete.
