Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-151
Error Messages and Codes
Controller Error
The printer controller has detected error. The following troubleshooting
procedure applies to these errors.
Applicable Chain Link
■ Chain Link 116-317: Controller Error (ROM Check Fail) (Main)
■ Chain Link 116-324: Controller Error (Illegal Exception)
■ Chain Link 116-327: Controller Error (Instruction Cache Error)
■ Chain Link 116-328: Controller Error (Data Cache Error)
Initial Actions
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Image Processor Board, PL9.1.20
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Image Processor Board
for correct installation.
2.Is the Image Processor Board
correctly installed?
Go to step 2. Reseat the
Processor
Board
(page 8-90).
2 Does the error still occur when the
printer is turned On?
Replace the
Processor Board
(page 8-90).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
