3-56 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Empty Print Cartridge (Yellow/Magenta/Cyan/Black)
The Print Cartridge has reached its end of life. The following troubleshooting
procedure applies to these errors.
Applicable Chain Link
■ Chain Link 093-935: Replace Yellow Cartridge
■ Chain Link 093-936: Replace Magenta Cartridge
■ Chain Link 093-937: Replace Cyan Cartridge
■ Chain Link 093-938: Replace Black Cartridge
Initial Actions
■ Check the Print Cartridge life using CentreWare IS.
■ Cycle printer power.
■ If problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Print Cartridge (Y/M/C/K),
PL5.1.17-20
■ MCU Board, PL9.2.13
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Print Cartridge for correct
installation.
2.Is the Print Cartridge correctly
installed?
Go to step 3. Reseat the Print
Cartridge
(page 8-11).
Go to step 2.
2 Does the error still occur? Go to step 3. Complete.
3 1.Replace the Print Cartridge
(page 8-11).
2.Does the error still occur?
Replace the
MCU Board
(page 8-88).
Complete.
