Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-59
Error Messages and Codes
Non-Xerox Print Cartridge Error (Yellow/Magenta/Cyan/Black)
The Print Cartridge CRUM ID error indicates that a non-Xerox Print Cartridge
is installed. The following troubleshooting procedure applies to these errors.
Applicable Chain Link
■ Chain Link 093-960: Non-Xerox Toner, Invalid Yellow
■ Chain Link 093-961: Non-Xerox Toner, Invalid Magenta
■ Chain Link 093-962: Non-Xerox Toner, Invalid Cyan
■ Chain Link 093-926: Non-Xerox Toner, Invalid Black
Initial Actions
■ Check the Print Cartridge life using CentreWare IS.
■ Cycle printer power.
■ If problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Print Cartridge (Y/M/C/K),
PL5.1.17-20
■ MCU Board, PL9.2.13
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Print Cartridge for correct
installation.
2.Is the Print Cartridge correctly
installed?
Go to step 3. Reinstall the
Print Cartridge
(page 8-11).
2 Does the error still occur? Go to step 3. Complete.
3 Reseat the Print Cartridge. Does the
error still occur?
Go to step 4. Complete.
4 1.Replace the Print Cartridge
(page 8-11).
2.Does the error still occur?
Replace the
MCU Board
(page 8-88).
Complete.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
