Xerox Phaser 6180MFP Service Manual

3-46 Phaser 6180MFP Multifunction Printer Service Manual
Error Messages and Codes
Consumable/Routine Maintenance Errors
Insert Fuser
The printer does not detect the presence of the Fuser. The following
troubleshooting procedure applies to this error.
W
arn
i
ng
The Fuser may be hot. Turn the printer power Off and allow at least 5
minutes for the Fuser to cool before removing the Fuser.
Applicable Chain Link
■ Chain Link 010-317: Insert Fuser (IOT Fuser Detached)
Initial Actions
■ Ensure that the Fuser latches are fully locked.
■ Cycle printer power.
■ If the problem persists, follow the procedure below.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map Reference
■ Fuser, PL6.1.10
■ MCU Board, PL9.2.13
■ LVPS, PL9.2.14
■ LVPS Harness, PL10.1.3
■ Fuser Harness, PL10.1.5
■ “Map 1 - Electrical and Drive” on
page 10-10
■ “Map 4 - LVPS and MCU Board” on
page 10-13
■ “Fuser” on page 10-40
Troubleshooting Procedure Table
Step Actions and Questions Yes No
1 1.Check the Fuser for correct
installation.
2.Is the Fuser correctly installed?
Go to step 2. Reseat the
Fuser
(page 8-12).
Go to step 2.
2 Does the error still occur when the
printer is turned On?
Go to step 3. Complete.
3 1.Check the wiring harness
connectors P/J17, P/J171, P/J47, P/
J501, and P/J14 between the MCU
Board and the Fuser Unit.
2.Are the connectors securely
connected?
Go to step 4. Reconnect the
connectors.

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
