Xerox Phaser 6180MFP Service Manual

Phaser 6180MFP Multifunction Printer Service Manual 3-45
Error Messages and Codes
18 Check the Front Cover Harness for
continuity.
1.Disconnect P/J2720 from the
Duplex Unit Harness.
2.Disconnect P/J272 from the Right
Side Harness.
Check continuity between P/J2720
<=> P/J272.
Go to step 19. Replace the
Front Cover
Harness.
19 Check the Right Side Harness for
continuity.
1.Disconnect P/J272 from the Right
Side Harness.
2.Disconnect P/J27 from the MCU
Board.
3.Check continuity between P/J272
<=> P/J27.
Go to step 20. Replace the
Right Side
Harness.
20 Check the Duplex Unit Board signal.
1.Disconnect P/J27 from the MCU
Board.
2.Is there +3.3 V across ground <=>
J27-A15 pin on the MCU Board
when the Interlock Switch is
activated?
Go to step 21. Replace the
MCU Board
(page 8-88).
21 Does the error occur when the printer
is turned On?
Replace the
Duplex Unit
(page 8-115).
Complete.
Troubleshooting Procedure Table (continued)
Step Actions and Questions Yes No

Xerox Phaser 6180MFP Specifications

General

Print Technology	Laser
Functions	Print, Copy, Scan, Fax
Duplex Printing	Manual
Scan Type	Flatbed, ADF
Fax Capability	Yes
Fax Transmission Speed	33.6 Kbps
Standard Paper Capacity	250 sheets
Maximum Paper Capacity	500 sheets
Max Paper Size	8.5 x 14 in
Connectivity	USB 2.0, Ethernet
Scan Resolution	1200 x 1200 dpi
Supported Paper Sizes	Letter, Legal, Executive, A4, A5, B5
Operating System Compatibility	Windows, Mac OS, Linux
Maximum Print Resolution	600 x 600 dpi
