Xerox Phaser 6180MFP Service Manual

1-30 Phaser 6180MFP Multifunction Printer Service Manual
General Information
Alignment Specifications
Characteristic Specifications
Copy Scan Print
System ADF
Document
Glass
ADF Printer
Lead Registration ±3.0 mm ±4.0 mm ±1.0 mm ±2.0 mm ±2.0 mm
Side Registration ±3.5 mm ±4.5 mm ±1.0 mm ±2.0 mm ±2.5 mm
Lead Skew
(180 mm)
±2.2 mm ±2.9 mm ±1.1 mm ±1.8 mm ±1.1 mm
Side Skew
(280 mm)
±3.7 mm ±4.8 mm ±1.7 mm ±2.8 mm ±2.0 mm
(converted
from
perpendicula
rity)
Magnification
accuracy in the
horizontal direction
(180 mm)
Applied when 100%
±3.6 mm ±3.6 mm ±2.7 mm ±2.7 mm ±0.9 mm
(100±0.5%
@180 mm)
Magnification
accuracy in the
vertical direction
(280 mm)
Applied when 100%
±4.2 mm ±4.2 mm ±2.8 mm ±2.8 mm ±1.4 mm
(100±0.5%
@280 mm)
Magnification
accuracy in the
vertical direction
(140 mm)
Applied when 50%
±2.1 mm ±2.1 mm ±1.4 mm ±1.4 mm ±0.7 mm
(converted
from 280
mm)
Magnification
accuracy in the
vertical direction
(200 mm)
Applied when 200%
±3.0 mm ±3.0 mm ±2.0 mm ±2.0 mm ±1.0 mm
(converted
from 280
mm)
Perpendicularity
(140 mm)
±2.0 mm ±3.1 mm ±1.0 mm ±2.1 mm ±1.0 mm
Linearity (vertical)
(280 mm)
±1.1 mm ±1.6 mm ±0.5 mm ±1.0 mm ±0.6 mm
Linearity (slant)
(200 mm)
±2.1 mm ±2.9 mm ± 1.2 mm ±2.0 mm ±0.9 mm
(±1.1 mm/
254.5 mm
conversion)
Parallelism
(280 mm)
±3.3 mm ±4.1 mm ±2.0 mm ±2.8 mm ±1.3 mm
